Non-Aqueous Butyl Benzoate Based Blue PEDOT:Complex Dispersion
Used for applications in HIL, printed OLED/QLED, and displays
| |
HIL 8 PEDOT Complex is a pH neutral non-aqueous butyl benzoate based blue PEDOT complex dispersion, with an alternative counter ionomer of PSEBS. HIL 8 PEDOT Complex is designed as hole injection layer material (HTL) for OLEDs, OPVs, and perovskite solar cells.
Deep Work Function
Matching interfacial energy levels
Versatile use
Ideal for applications in HIL, printed OLED/QLED, and displays
High Quality
Quality formulation
Tailored Low Conductivity
Low conductivity
Technical Data
| Product Name | Clevios™ HIL 8 |
|---|---|
| Solvent | Butyl benzoate |
| Composition | PEDOT complex |
| Solid Content | 3.0 – 4.0 wt.% |
| Work Function | 5.0 – 5.1 eV |
| Resistivity | 100 – 10000 Ω/cm |
| Sheet Resistance | 10E6 Ω/sq |
| Conductivity | Low conductivity |
| Particle Size Distribution | N/A |
| Viscosity | 5 – 9 mPa.s |
| pH Value | pH neutral |
| Packaging | 25 ml of solution sealed in a light resistant bottle with temperature indicator |
| Storage | 3 – 5 °C |
Spin Speed Data
MSDS Document
Resources and Support
For the deposition of thin films of PEDOT materials on a freshly prepared surface, we recommend using a vacuum-free spin coater and following this five-step process:
PEDOT synthesis involves the oxidative chemical or electrochemical polymerization of EDOT monomer. The choice of counterions and polymerization method significantly affects the conductivity, work function, and stability of the resulting PEDOT polymer.
