Product Details
＋
BK3-P1, Indicator, 48x24mm, 100-240VAC, Pt100 RTD Input, -199.0-600 Deg C Display Range
- 3.5-digit displays suit most industries including Temperature, Humidity, Pressure (0.5s response)
- Drip-proof / Dust-proof IP66 (front panel only)
- UL/CE Approved
- Each unit needs just 100.2 mm depth panel space
- EC Compliant
Specification
| Hanyoung Nux Part Number | BK3-P1 |
| Control Output 1 (Heat) | N/A |
| Control Output 2 (Cool) | N/A |
| Input | P100 RTD (-199.0-600.0 Deg C) |
| Alarm | N/A |
| Option 1 | N/A |
| Mounting Style | 48 x 24mm Panel Mount |
| Supply Voltage | 85 - 265VAC |
| Termination Style | Screw |
| Weight | 250g |
| Factory Pack Qty | 1 |
| ROHS | Yes |
| UL | Yes |
| CE | Yes |
